316L / 1.4404 Welded Coiled Seamless Stainless Steel Pipe For Multi - Core Tube

Ask Lasest Price
Brand Name :	MTSCO
Model Number :	MTSCOSSCT37
Certification :	ISO 9001 & PED & AD2000
Price :	5500-10000USD/TON
Payment Terms :	T / T ; L / C
Supply Ability :	300 Tons / Month
Delivery Time :	30 Days

Add to Cart

Product Details
Company Profile

316L / 1.4404 Welded Coiled Seamless Stainless Steel Pipe For Multi - Core Tube

316L / 1.4404 Stainless Steel Welded Coiled Tube For Multi-core Tube

Where the multi-core coiled tubing used ?

Mtsco’ s multi-core tubes are used for pneumatic and hydraulic remote control, measuring and monitoring systems. materials are ASTM TP316/ 316L, TP304/304L.

Ordering code number	Tube size (O.D x Thickness x Core)	Overall Diameter (.mm)	Sheath Thickness (.mm)	Bundle Weight (kg/M)	Max Pressure (Bar)
HTD-1	6×1.0×1	8	1.0	0.15	Working:180Bar Test:270Bar
HTD-2	6×1.0×2	20	2.0	0.60
HTD-3	6×1.0×3	21	2.0	0.75
HTD-4	6×1.0×4	24	2.0	0.82
HTD-5	6×1.0×5	25	2.0	0.90
HTD-6	6×1.0×6	27	2.0	1.04
HTD-7	6×1.0×7	27	2.0	1.15
HTD-8	6×1.0×8	32	2.2	1.40
HTD-9	8×1.0×1	10	1.0	0.28
HTD-10	8×1.0×2	24	1.8	0.89
HTD-11	8×1.0×3	26	2.0	1.12
HTD-12	8×1.0×4	28	2.0	1.33
HTD-13	8×1.0×5	31	2.0	1.67
HTD-14	8×1.0×6	34	2.0	2.00
HTD-15	8×1.0×7	34	2.0	2.15
HTD-16	8×1.0×8	40	2.2	2.60
HTD-17	10×1.0×1	13	1.0	0.34
HTD-18	10×1.0×2	28	1.8	1.18
HTD-19	10×1.0×3	31	2.0	1.60
HTD-20	10×1.0×4	34	2.0	1.97
HTD-21	10×1.0×5	37	2.0	2.20
HTD-22	10×1.0×6	40	2.0	2.40
HTD-23	10×1.0×7	40	2.0	2.52
HTD-24	10×1.0×8	48	2.5	3.20
HTD-25	12×1.0×1	14	1.0	0.41
HTD-26	12×1.0×2	34	2.0	1.35
HTD-27	12×1.0×3	36	2.0	1.96
HTD-28	12×1.0×4	39	2.0	2.37
HTD-29	12×1.0×5	43	2.0	2.70
HTD-30	12×1.0×6	47	2.0	3.00
HTD-31	12×1.0×7	47	2.0	3.14
HTD-32	12×1.0×8	55	2.5	3.90

The multi-core tube consists of one to nine stainless steel tubes laid up spirally inside an extruded outer PVC sheath. For easy identification and protection purposes each individual tube is PVC sheathed in a different color. The extruded outer sheath is made of oil and seawater resistant, weatherproof, flame retardant, corrosion and acid resistant PVC. The multi-core tube (outer sheath) is continuously marked at every one meter throughout the entire length for easy installation. Heat shrinkable products provide complete water sealing, abrasion and corrosion protection under all conditions.
