    316L/S32205/N08825 Welded Downhole Coiled Tubing For Chemical Injection Line

    Ask Lasest Price
    Brand Name : MTSCO
    Model Number : MTSCOSSCT09
    Certification : ISO 9001 & PED
    Price : 5500-10000USD/TON
    Payment Terms : T / T ; L / C
    Supply Ability : 300 Tons / Month
    Delivery Time : 30 Days
    • Product Details
    • Company Profile

    316L/S32205/N08825 Welded Downhole Coiled Tubing For Chemical Injection Line

    316L/S32205/N08825 Welded Downhole Coiled Tubing For Chemical Injection Line

    MTSCO has been supplying industrial tubing to the oil and gas industry for more than a decade. In recent years, we have continued to make breakthroughs in the field of coiled tubing, downhole control lines, and chemical injection control lines. Our coiled tubing has been successfully used in certain harsh subsea and downhole conditions, and through continuous research and development, is able to meet the stringent quality requirements of the oil and gas industry and other industries.


    Material: TP316L, S32205, Alloy825/N08825, Alloy400/ N04400, Alloy625 N06625
    Outer Diameter: 1/4“, 3/8”,1/2“
    Wall Thickness: 0.035”,0.049“,0.065”
    Length : PER FT
    Application : Inhibitor Supply control
    Pressure Rating : 15000 Psi
    Type : HYDRAULIC FLAT PACK
    Additional Material Specs : PVDF Encapsulation

    Size : 3lines x 1/4" 0.049WT


    Additional Features : Color coded, oil filling, fluid filling

    Encapsulation Size : 33 x 11mm



    Where the coiled tubing used ?

    1 . Control tubing in oil and gas well
    2 . Instrument tubing
    3 . Chemicl injection tubing line
    4 . Pre-insulated tubing
    5 . Electric heating or steam heating tubing line
    6 . Hater tubing line


    Chemical Composition :

    MaterialASTM A269 Chemical Composition % Max
    CMnPSSiCrNiMoN BNbTi
    TP3040.0820.0450.03118.0-20.08.0-11.0^^^.^
    TP304L0.03520.0450.03118.0-20.08.0-12.0^^^^
    TP3160.0820.0450.03116.0-18.010.0-14.02.00-3.00^^^
    TP316L0.035 D20.0450.03116.0-18.010.0-15.02.00-3.00^^^
    TP3210.0820.0450.03117.0-19.09.0-12.0^^^5C -0.70
    TP3470.0820.0450.03117.0-19.09.0-12.0  10C -1.10^

    316L/S32205/N08825 Welded Downhole Coiled Tubing For Chemical Injection Line

    About MTSCO:


    Who MTSCO IS?


    MTSCO established in 2006, during many years’ development, now becomes a large and professional industrial piping system provider, serving customers from more than 100 countries and regions.



    What products can MTSCO provide?


    316L/S32205/N08825 Welded Downhole Coiled Tubing For Chemical Injection Line



    What materials can MTSCO provide?


    Austenitic: 304/L/H/N,316/L/H/N/Ti,321/H,309/H,310S,347/H,317/L904L

    Duplex steel: 31803,32205,32750,32760

    Nickel Alloy:

    UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230, R30556

    UNS N06600, N06601, N06617, N06625, N07718, N07750, N08800, N08810, N08811, N08825, N09925, N08926

    UNS N04400, N05500

    Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH

    Nickel: N4/UNS N02201, N6/UNS N02200


    How can MTSCO service customers?


    MTSCO's ISO9001 Quality System is issued by TUV. Our full and professional inspection reports contain two parts, one is self-inspection of the requirements beyond ISO9001, which is 100% inspected by our own QC; another is 100% inspected by professional QC teams.


    316L/S32205/N08825 Welded Downhole Coiled Tubing For Chemical Injection Line


    For more information, you are welcome to contact us by email. Thank you for your interest.
