1/4" UNS N06625 Oilfield Encapsulated Control Line 3lines With Flat
Pack
An increasing number of projects in the oil service industry
require the use of continuous lengths of stainless steel control
lines. They are used in a variety of applications, including
chemical injection, hydraulic control, instrumentation umbilicals
and flowline control.
MTSCO offers products for all of these applications, helping
customers reduce operating costs and improve recovery methods.
Control Line Technical Details:
| line 1 | line 2 | line 3 |
| Outside diameter (in) | 1/4" | 1/4" | 1/4" |
| Wall thickness (in) | 0.049" | 0.049" | 0.035" |
| Color coding | According to customer's request |
| Flush and Filling | Oil |
| Manufacturing specification | ASTM B704 | ASTM B704 | ASTM B704 |
| Yield strength (psi) | ≥34954 | ≥34954 | ≥34954 |
| Test Pressure (psi) | 5000 | 5000 | 5000 |
| Maximum Hardness (HB) | 85-90HRb | 85-90HRb | 85-90HRb |
| Tolerance: WT(%) OD (mm) | WT ±5% OD±0.003 | WT ±5% OD±0.003 | WT ±5% OD±0.003 |
| Material: TP316L, S32205, Alloy825/N08825, Alloy400/ N04400, Alloy625 N06625 |  |
| Outer Diameter: 1/4“, 3/8”,1/2“ |
| Wall Thickness: 0.035”,0.049“,0.065” |
| Length : PER FT |
| Application : Inhibitor Supply control |
Pressure Rating : 15000 Psi |
| Type : HYDRAULIC FLAT PACK |
| Additional Material Specs : PVDF Encapsulation |
Size : 3lines x 1/4" 0.049WT
|
| Additional Features : Color coded, oil filling, fluid filling |
Encapsulation Size : 33 x 11mm
|
MTSCO has been supplying industrial tubing to the oil and gas
industry for more than a decade. In recent years, we have continued
to make breakthroughs in the field of coiled tubing, downhole control lines, and chemical injection
control lines. Our coiled tubing has been successfully used in certain harsh
subsea and downhole conditions, and through continuous research and
development, is able to meet the stringent quality requirements of
the oil and gas industry and other industries.
